High-voltage Battery Pyro Fuse for Audi Skoda Cupra Seat HV Battery after Crash 83mm x 69mm

High-voltage battery disconnect pyro fuse that fits various VW, Audi and Porsche HV battery equipped models. Used for replacement after detected crash (incident).

Compatible part numbers:

• 9J1915463A
• 0Z195463H
• 0Z1 954 63H
• 0Z1 954 63H
• 0Z1915463E
• 0Z1 915 463E
• 0Z1 915 463 E
• 0Z1915463F
• 0Z1 915 463F
• 0Z1 915 463 F
• KSS-ACT-2023484
• 1008-P1-69260767

This part is essential for maintaining the safety and functionality of your electric vehicle, and it is compatible with several VW and Audi models. Regular diagnostics may highlight fault codes such as:

•           P160900 - Crash shut-off was triggered
•           P1CA700: Igniter for hybrid/high-voltage system fuse
•           P1CAC00: Hybrid/High-Voltage System blasting fuse triggered
•           P1CAB00 Igniter for hybrid/high-voltage system fuse Implausible signal
•           or other errors indicating issues with the pyro fuse that may require replacement

Very important note for anyone looking to purchase or replace this component:

PLEASE MAKE SURE THAT THIS COMPONENT FITS YOUR VEHICLE. There are usually three types of pyrofuses that can fit your model! Please make sure you order the correct one, no returns possible explicitly for this item! You can open up your HV battery in order to check what is the correct pyrofuse you need. Measure the measurements of your pyro fuse as well and compare to the product image measurements!

Measurements: 83mm x 69mm

Can fit for these models:

• VW Volkswagen ID.3
• VW Volkswagen ID.4
• VW Volkswagen ID.6
• VW ID.Buzz
• Audi GT e-tron
• Audi Q4 e-tron
• Skoda Enyaq iV
• Skoda Enyaq Coupe IV
• Cupra Born

For assistance, feel free to contact us: carmoduleseu@gmail.com

Shipping within EU.

Scope of delivery:

1x Pyro fuse for HV Battery

We can also assist remotely for removing the crash using ODIS-E and ODIS-S.

The High Voltage Battery Pyrofuse is a critical safety component specifically designed for Volkswagen (VW) and Audi electric vehicles, such as the VW ID.3, ID.4, and the Audi Q4 e-tron. This genuine OEM part, manufactured by Key Safety Systems (KSS) in Germany, acts as a high-voltage battery disconnect pyroswitch, ensuring the safe operation of the vehicle by preventing electrical hazards in case of a crash or malfunction. The pyrofuse is engineered to disconnect the high-voltage circuit by triggering a small explosive charge that breaks the electrical connection, thereby safeguarding both the vehicle and its occupants from potential electric shock or fire. It’s particularly vital in EVs, where managing high-voltage systems is crucial for safety.
